Premium Grade Copper Metal Foams
$0.00
In StockPremium Grade Copper Metal Foams
Stock No. | NCZFF102 |
PPI | 10 to 110, customization is also possible |
Bulk Density | 0.80-0.85 g/cc |
Purity | ≥99.9% |
Porosity | ≥70% , customization is also possible |
Dimension | 500 mm X 500 mm, customization is also possible |
Thickness | 1mm to 25mm, customization is also possible |
Physical Characteristics of Cu Foam
Compression Strength | 131 psi |
Tensile Strength | 1000 psi |
Shear Strength | 190 psi |
Modulus of Elasticity (Compression) | 107 kpsi |
Modulus of Elasticity (Tension) | 14.6 × 103 psi |
Shear Modulus | 40.9 kpsi |
Vickers Hardness | 35 |
Specific Heat | 0.385 J/g-°C |
Bulk Thermal Conductivity | 10.1 W/m-°C |
Coefficient of Thermal Expansion | 1.7 × 10-5 m/m–°C (0-100°C) |
Bulk Resistivity | 2.56× 10-5 ohm – in |
Melting Point | 1080 °C |
Copper foam available as open cell and closed cell. Please ask for customization while ordering.
Copper Metal Foams Related Information
Storage Conditions:
Airtight sealed, avoid light and keep dry at room temperature.
Please contact us for customization and price inquiry
Email: contact@nanochemazone.com
Note: We supply different size ranges of Nano and micron as per the client’s requirements and also accept customization in various parameters.
Description
Description
Note: For pricing & ordering information, please contact us at sales@nanochemazone.com
Please contact us for quotes on Larger Quantities and customization. E-mail: contact@nanochemazone.com
Customization:
If you are planning to order large quantities for your industrial and academic needs, please note that customization of parameters (such as size, length, purity, functionalities, etc.) is available upon request.
NOTE:
Images, pictures, colors, particle sizes, purity, packing, descriptions, and specifications for the real and actual goods may differ. These are only used on the website for the purposes of reference, advertising, and portrayal. Please contact us via email at sales@nanochemazone.com or by phone at (365) 888-7013 if you have any questions.
Related products
-
Aluminum Metal Foam
Product: Aluminum Metal Foam (Closed Cell or Open Cell, 2-11 mm)
Stock No. NCZFF108 Density 0.1 to 0.35 g/cm³ Pore Size 2-11 mm, 5 mm (Closed Cell as well as Open Cell) Porosity 60-90%, customization is also possible Compressive Strength 44 Mpa Blending Strength 27 Mpa Acoustic Absorptive 0.48 Foam Size 100 x 100 x 5 mm, customization is also possible Physical Characteristics Aluminum Metal Foam
Heat Resistivity 660 °C Acoustic Frequency Between 125 and 2000 HZ Noise Reduction Coefficient >0.4 Thermal Insulation Properties About 1 / 400 of metal Aluminum Electromagnetic Wave Frequency Between 2.6 and 18 GHZ Electromagnetic Shielding Property Up to 60 – 90 dB Resistivity 100 Times Over Metal Aluminum Aluminium Metal Foam Open Cell or Closed Cell, Both are Available (Ask for Customization)
$0.00 -
Stainless Steel Foam
Stock No. NCZFF107 PPI 10 to 110, customization is available Surface Density 346g/m^2 Purity ≥99.9% Porosity ≥95%, customization is available Length 300 mm, customization is available Width 300 mm, customization is available Thickness 3 mm, customization is available Stainless Steel Foam Available in Open Cell as well as Closed Cell
$0.00 -
Polyethylene Foam
CAS: 9002-88-4
Product Name Polyethylene Foam
Product Code NCZFF110 Purity >99.9% Density 1.2 (LB/Cubic Ft. Color White Cell Count 18 (cells/inch) COMPRESSIVE STRENGTH
25% 7 (LB/In. Sq.) 50% 12 (LB/In. Sq.) COMPRESSION SET
2 hours 30 % 24 hours 24 % Compression Creep 5 % Water Absorption 0.06 LB/Sq. Ft. Thermal Stability <2 % Service Temperature -30 to 180 °F Contains Fire Retardant Additives No Polyethylene Foam Closed Cell as well as Open Cell (Ask for customization while ordering)
$0.00 -
Reticulated Vitreous Carbon Foam /Glassy Carbon Foam
Open cell carbon foam
Reticulated Vitreous Carbon Foam
Product Carbon Foam (Purity: 99.9%, Thickness: 5 mm)
Materials Carbon Foam Stock No NCZFF112 CAS 7440-44-0 Purity 99.9% Thickness 2-10 mm, customization available Compression Strength 15-75 psi Tensile Strength 25-50 psi Shear Strength 4.4×103 psi Hardness 6-7 Mohs Specific Heat 0.3 BTU/lb °F Shear Modulus 4.4 × 103 psi Bulk Thermal Conductivity 0.021-0.29 BTU/ft •hr•°F Coefficient of Thermal Expansion 1.2 × 10-6 in/in°F (0-100°C) Bulk Resistivity 12.7 × 10-2 ohm • in Temperature In air 600°F Limitations Inert environment 6330°F Pore Sizes 0.040″, customization is also possible Size 50 x 50 mm, 100 x 100 mm, 200 x 300 mm (Ask for customization) Reticulated vitreous carbon foam Available in Open Cell as well as Closed cell
RVC foam density is customizable on request while ordering. reticulated vitreous carbon foam reticulated foam.
Application: Reticulated Vitreous Carbon Foam for Electrochemistry Electrodes, High Surface Area, Temperature Stability, etc. RVC foam reticulated foam
12.7 × 10-2 ohm • in of RVC foam
50 x 50 x 5 mm RVC Foam with 80 PPI is ready stock, customization is also possible in RVC foam.
Product: Carbon Foam (Purity: 99.9%, Thickness: 5 mm) reticulated vitreous carbon foam, RVC foam, Reticulated foam
$0.00 -
Aluminium Metal Foams Panel
Aluminium Metal Foams
Product Aluminium Foam Panel
Stock No. NCZFF113 CAS No. 7429-90-5 Purity 99.9% Cell Type Closed Cell as well as Open Cell, customization is available Density 0.35g /cm³~ 0.7g /cm³ Tensile Strength 1.3~2.0 Mpa Compressive Strength 1.5~2.0 Mpa Thermal Conductivity 0.268 W/m.K Melting Point 780 °C Shape Foam Panel Number of pores/inch (PPI) 10-100 PPI, customization is possible on demand Thickness 1 mm – 250 mm, customization is possible on demand Available Sizes 100 x 100 mm, 500 x 500 mm, 600 x 600 mm, 1000 x 500 mm, 1200 x 600 mm, 2000 x 800 mm, Size customization is possible on demand Storage Conditions Stored in a cool and dry place, away from the fire, Heat source Aluminium Metal Foam Open Cell or Closed Cell, Both are available (Ask for Size Customization)
$0.00 -
Materials Aluminum Foil
Stock No: NCZ-F-0017 Purity: > 99.99% Thickness 10 micron-2 mm, customization is available on demand Temper H18 Application Lithium-Ion Battery CAS Number 7429-90-5 Nanochemazone produces to many standard grades when applicable, including Mil Spec (military grade); ACS, Reagent and Technical Grade; Food, Agricultural and Pharmaceutical Grade; Optical Grade, USP and EP/BP (European Pharmacopoeia/British Pharmacopoeia) and follows applicable ASTM testing standards. Typical and custom packaging is available, as is additional technical and safety (MSDS) data. Please contact us for information on lead time and pricing above.
Aluminum Foil Related Information
Storage Conditions:
Airtight sealed, avoid light and keep dry at room temperature.
Please contact us for customization and price inquiry
Email: contact@nanochemazone.com
Note: We supply different size ranges of Nano and micron as per the client’s requirements and also accept customization in various parameters.
$0.00
