Halogen-Free Conductive Silver Paste

Product Name	Halogen-Free Conductive Silver Paste
CAS No.	N/A
Appearance	Paste
Purity	≥99.9%
Ingredient	N/A
Product Code	NCZ-24AV-101

halogen-free conductive silver paste is a silver-gray high-performance halogen-free conductive ink. This material is suitable for screen printing. It has excellent printability, moderate baking temperature, good bending performance, adhesion and conductivity.

Product Properties:

Grade	Halogen-Free Conductive Silver Paste
Condition	paste
Appearance	silver gray
Packing	100 grams to 1 Kg, ≤ 100%.
Tightness	Good
Hardness	(45-degree angle, 2Kg pressure pencil slurry pushing surface): ≥ 2H;
Adhesion(N)	(3M600 adhesive tape is stuck for 60s at an angle of 135 degrees 10cm/s): no falling off
Sheet Resistance（mΩ/□）	＜12

Recommended Using Process:

Substrate: PET or PC.

Operating temperature: about 25 ℃ is recommended.

Screen: 200~300 mesh polyester screen or stainless-steel screen printing.

Diluent: special thinner provided by our company shall be fully mixed before use.

Hardening conditions (recommended): drying temperature 145 ℃~150 ℃, drying time 40~90min.

Cleaning agent: butyl acetate, cyclohexanone

Halogen-Free Conductive Silver Paste Properties /Description

Halogen-Free Conductive Silver Paste is generally immediately available in most volumes. Nanochemazone produces many standard grades when applicable, including Mil Spec (military grade); ACS, Reagent and Technical Grade; Food, Agricultural, and Pharmaceutical Grade; Optical Grade, USP and EP/BP (European Pharmacopoeia/British Pharmacopoeia) and follows applicable ASTM testing standards. Typical and custom packaging is available. Additional technical, research, and safety (MSDS) information are available, as is a Reference Calculator for converting relevant units of measurement.

Related Information:

Storage Conditions:

Airtight sealed, avoid light, and keep dry at room temperature.

Please get in touch with us for customization and price inquiry

Email: contact@nanochemazone.com

Note: We supply different size ranges of Nano and micron as per the client’s requirements and accept customization in various parameters.

Description

Note: For pricing & ordering information, please contact us at sales@nanochemazone.com
Please contact us for quotes on Larger Quantities and customization. E-mail: contact@nanochemazone.com

Customization:

If you are planning to order large quantities for your industrial and academic needs, please note that customization of parameters (such as size, length, purity, functionalities, etc.) is available upon request.
