| Product Name |
Ag-6811 Halogen-Free Conductive Silver Paste
|
| CAS No. |
N/A |
| Appearance |
Powder |
| Purity |
≥99.9% |
| APS |
1-5µM (Can be customized) |
| Ingredient |
Ag |
| Product Code |
NCZ-24AV-121 |
halogen-free conductive silver paste -Ag-6811 is a silver-gray high-performance halogen-free conductive ink. This material is suitable for screen printing. It has excellent printability, moderate baking temperature, good bending performance, adhesion and conductivity.
Product Properties:
| Grade |
Ag-6811 Halogen-Free Conductive Silver Paste |
| Condition |
paste |
| Appearance |
silver gray |
| Flexibility |
2 kg, 5 changes ≤ 100%. |
| Tightness |
Good |
| Hardness |
(45 degree angle, 2Kg pressure pencil slurry pushing surface): ≥ 2H; |
| Adhesion(N) |
(3M600 adhesive tape is stuck for 60s at an angle of 135 degrees 10cm/s): no falling off |
| Sheet Resistance（mΩ/□） |
＜12 |
Recommended Using Process:
Substrate: PET or PC;
Operating temperature: about 25 ℃ is recommended;
Screen: 200~300 mesh polyester screen or stainless steel screen printing;
Diluent: special thinner provided by our company shall be fully mixed before use;
Hardening conditions (recommended): drying temperature 110 ℃~120 ℃, drying time 20~30min;
Cleaning agent: butyl acetate, cyclohexanone.
Matters Needing Attention:
- Safe use: Halogen free conductive ink contains organic solvent, which should be well ventilated during use to avoid excessive steam inhalation; Ink is harmful if swallowed, inhaled or in contact with skin, so it should be thoroughly cleaned immediately after use to avoid contact with eyes, skin or clothing. When not in use, cover tightly to avoid breathing volatile gas, and maintain air circulation when using;
- This ink is a ready to use product and does not need to be diluted. If it needs to be diluted, please use the special thinner of our company. The added amount should not exceed 0.5% (weight ratio). Too much thinner will directly affect the ink performance;
- Line thickness ＞ 5 μ m. Excellent bending resistance;
Ag-6811 Halogen-Free Conductive Silver Paste Properties /Description
Ag-6811 Halogen-Free Conductive Silver Paste is generally immediately available in most volumes. Nanochemazone produces many standard grades when applicable, including Mil Spec (military grade); ACS, Reagent and Technical Grade; Food, Agricultural, and Pharmaceutical Grade; Optical Grade, USP and EP/BP (European Pharmacopoeia/British Pharmacopoeia) and follows applicable ASTM testing standards. Typical and custom packaging is available. Additional technical, research, and safety (MSDS) information are available, as is a Reference Calculator for converting relevant units of measurement.
Related Information:
Storage Conditions:
Airtight sealed, avoid light, and keep dry at room temperature.
Please get in touch with us for customization and price inquiry
Email: contact@nanochemazone.com
Note: We supply different size ranges of Nano and micron as per the client’s requirements and accept customization in various parameters.
