Silicon Wafer Undoped
$0.00
In StockSilicon Wafer Undoped
| Product Name |
Silicon Wafer Undoped |
| Product Code | NCZ-WM-0011 |
| CAS | 7440-21-3 |
| Diameter | 4″ (100 mm), also available in 2, 3, 5, 6, 12″ |
| Doping | Undoped |
| Crystal Orientation | <100> other orientations are also possible |
| Surface | Single/Both Side Polished |
| Thickness | 500 μm / Ask for customization |
| Resistivity | 1-10 ohm-cm |
| Crystal method | CZ |
| RRG | ≤12 % |
| Oxygen Contents | 12.5-16.5 ppm |
| Carbon Contents | ≤1 ppm |
Please enquire for other wafers having different thicknesses, Diameter, Length, and sizes, etc.
If the item shown is not exactly what you require please let us know by sending us a message.
Description
Note: For pricing & ordering information, please contact us at sales@nanochemazone.com
Please contact us for quotes on Larger Quantities and customization. E-mail: contact@nanochemazone.com
Customization:
If you are planning to order large quantities for your industrial and academic needs, please note that customization of parameters (such as size, length, purity, functionalities, etc.) is available upon request.
NOTE:
Images, pictures, colors, particle sizes, purity, packing, descriptions, and specifications for the real and actual goods may differ. These are only used on the website for the purposes of reference, advertising, and portrayal. Please contact us via email at sales@nanochemazone.com or by phone at (365) 888-7013 if you have any questions.
