Silicon Wafer with Silicon Dioxide Layer
$0.00
In StockSilicon Dioxide Wafer
Thermally grown sio2
oxide-coated silicon wafer
Product Name | Silicon Wafer Silicon Dioxide Layer |
Product Code | NCZ-WM-0015 |
CAS | 7440-21-3 |
Diameter | 100 mm, also available in 2, 3, 5, 6, 12″ |
Type | P/N Type, Undoped |
Orientation | <100> /other orientations are also available |
Surface | Single /Both Side Polished |
Thickness | 400 μm, ask for other wafer thickness |
Resistivity | 0.01-0.02 Ω-cm |
SiO2 Thickness Layer | 200 nm (customization available) |
Please enquire for other wafers having different thicknesses, Diameter, Length, and sizes, etc.
If the item shown is not exactly what you require please let us know by sending us a message
Description
Note: For pricing & ordering information, please contact us at sales@nanochemazone.com
Please contact us for quotes on Larger Quantities and customization. E-mail: contact@nanochemazone.com
Customization:
If you are planning to order large quantities for your industrial and academic needs, please note that customization of parameters (such as size, length, purity, functionalities, etc.) is available upon request.
