Nanostructured Carbon Screen Printed Electrodes
$0.00
In Stock| Product Name |
Orion Screen Printed Electrodes |
| Product Code | NCZSPE105-19 |
| Diameter of WE | 2 mm, 3 mm, 4 mm , 5 mm |
| Size of RE | 0.5 x 1 mm |
| Ratio CE/WE Surface Area | 4/1 |
| Shape | Rectangle |
| Overall Dimension | 50 x 10mm |
| Thickness | 0.5mm |
| Thickness of Coated Material | 10 µm |
| Working Electrode | Graphite, Gold, Graphene, CNT, Platinum, Silver (customization possible) |
| Counter Electrode | Graphite, Gold, Silver |
| Reference Electrode | Ag/AgCl |
| Substrate | Valox FR1 |
| Packaging | 50, 100, 200, 500, 1000 Pcs |
Description
Note: For pricing & ordering information, please contact us at sales@nanochemazone.com
Please contact us for quotes on Larger Quantities and customization. E-mail: contact@nanochemazone.com
Customization:
If you are planning to order large quantities for your industrial and academic needs, please note that customization of parameters (such as size, length, purity, functionalities, etc.) is available upon request.
NOTE:
Images, pictures, colors, particle sizes, purity, packing, descriptions, and specifications for the real and actual goods may differ. These are only used on the website for the purposes of reference, advertising, and portrayal. Please contact us via email at sales@nanochemazone.com or by phone at +1-780-612-4177 if you have any questions.
