| Product Name |
Inconel 718 Powder
|
| CAS No. |
7440-02-0 |
| Appearance |
Powder |
| Purity |
≥99.9% |
| APS |
1-5 µM, 15-53 µM (Can be customized),
Ask for other available size range. |
| Ingredient |
Ni/Fe/Cr |
| Product Code |
NCZ-24AV-106 |
Inconel 718 (IN718) is a well-known nickel-based superalloy that is extensively used in high-value-added engineering applications such as jet engines in aerospace and steam generators in nuclear power plants, as well as in the defence and marine sectors. It has excellent mechanical properties, fatigue resistance, and corrosion resistance.
Product Specification
| Composition (Wt%） |
| In718 |
Cr |
Mo |
Nb |
Co |
Fe |
Al |
| 17.0-21.0 |
2.8-3.3 |
4.75-5.5 |
≤1 |
Bal. |
0.2-0.8 |
| Ti |
Si |
Ni |
O |
N |
|
| 0.65-1.15 |
≤0.35 |
50-55 |
≤500ppm |
≤100ppm |
|
Common Size:15-45um,15-53um,45-106um,45-150u,-200/-300/-400/-500/-600mesh etc,.
| No |
Name |
Chemical Composition (Wt%) |
| 1 |
18Ni300 |
Ni17-19，Mo4.5-5.2，Co8.5-9.5，Ti0.6-0.8，Al0.05-0.15，Fe(Bal.) |
| 2 |
Hastelloy Alloy |
Fe17-20，Cr20.5-23，Mo8-10，W0.2-1，Co0.5-2.5，C0.05-0.15，Ni(Bal.) |
| 3 |
AlSi10Mg |
Si9-11，Mg0.2-0.45，Al(Bal.) |
| 4 |
CoCrW |
Cr26.5-29，W7-9，Si1.2-1.9，Co(Bal.) |
| 5 |
Co28Cr6Mo |
Cr27-29，Mo5-7，Co(Bal.) |
| 6 |
Spherical Ti Powder |
Ti≥99.9 |
| 7 |
TC4 |
Al5.5-6.8，V3.5-4.5，Ti(Bal.) |
| 8 |
TA15 |
Al5.5-7.1，V0.8-2.5，Mo0.8-2，Zr1.5-2.5，Al(Bal.) |
| 9 |
316L |
Cr16.00-18.00， Ni10.00-14.00，Mo2.00-3.00，Fe(Bal.) |
| 10 |
S136 |
Cr12.0-14.0，Si0.8-1.0，V0.15-0.4，C0.2-0.45，Fe(Bal.) |
| 11 |
In625 |
Cr20-23 , Mo8-10 , Nb 3.15-4.15 , Co≤1, Fe≤1 , Ni (bal.) |
| 12 |
In718 |
Cr17-21 , Mo2.8-3.3 , Nb 4.75-5.5 , Co≤1, Ni50-51 , Fe(Bal.) |
| 13 |
Spherical WC |
C3.7-4.2，W(Bal.) |
| 14 |
Spherical Cr Powder |
Cr≥99.9 |
| 15 |
Spherical Mo Powder |
Mo≥99.9 |
| 16 |
Spherical Ta Powder |
Ta≥99.9 |
| 17 |
Spherical W Powder |
W≥99.9 |
Mechanical Properties:
Tensile Strength/MPa:1350±20
Yield Strength/MPa:1065±20
Elongation After Break/%:30±5
Tensile Strength(650℃)/MPa:1015±10
Yield Strength(650℃)/MPa:860±10
Elongation After Break(650℃)/%:15±3
Product Properties
- Appearance：Grey spherical powder
- Tapping Density：4.89g/m3
- Apparent density: 4.18g/m3
- Flowability：18.1s/50g
- Size: 15-53um
- PSD: D10:23.18um, D50:35.68um, D90: 54.62um
Application
(1) 3D Printing
(2) powder metallurgy (PM),
(3) injection molding (MIM),
(4) spraying coating (SP) etc.
Inconel 718 powder, Nanochemazone, suppliers, factory, customized, price, cheap, for coating, for 3D printing, Inconel 718 Powder, Inconel 625 Powder
Inconel 718 Powder Properties /Description
Inconel 718 Powder is generally immediately available in most volumes. Nanochemazone produces many standard grades when applicable, including Mil Spec (military grade); ACS, Reagent and Technical Grade; Food, Agricultural, and Pharmaceutical Grade; Optical Grade, USP and EP/BP (European Pharmacopoeia/British Pharmacopoeia) and follows applicable ASTM testing standards. Typical and custom packaging is available. Additional technical, research, and safety (MSDS) information are available, as is a Reference Calculator for converting relevant units of measurement.
Related Information:
Storage Conditions:
Airtight sealed, avoid light, and keep dry at room temperature.
Please get in touch with us for customization and price inquiry
Email: contact@nanochemazone.com
Note: We supply different size ranges of Nano and micron as per the client’s requirements and accept customization in various parameters.
