Aluminum Nanofoam
$0.00
In StockAluminum Metal Foams
Product Name |
Aluminum Metal Foams |
Stock No. | NCZFF114 |
CAS | 7429-90-5 |
Purity | 99.9% |
Dimension | 100 mm×100 mm, customization is also possible |
Thickness | 5 mm, customization is also possible |
Pore size | 2-11 mm, customization is also possible |
Molecular Formula | Al |
Molecular Weight | 26.98 g/mol |
Density | 0.1~0.35 g/cm³ |
Porosity | 60-90%, customization is also possible |
Compressive Strength | 44 Mpa |
Bending Strength | 27 Mpa |
Acoustic absorptive | 0.48 |
Tensile Strength | 1.24 MPa |
Shear Strength | 1.31 MPa |
Modulus of Elasticity (Compression) | 103.08 MPa |
Modulus of Elasticity (Tension) | 101.84 MPa |
Shear Modulus | 199.95 MPa |
Vickers Pyramid Number | 35 HV |
Specific Heat | .895 J/g-C |
Bulk Thermal Conductivity | 5.8 W/m-C |
Bulk Resistivity | 2.84 × 10-5 ohm – in |
Aluminium Metal Foam Open Cell or Closed Cell in all size, PPI and thickness, Both are Available on demand (Ask for the customization)
Nanochemazone produces to many standard grades when applicable, including Mil Spec (military grade); ACS, Reagent and Technical Grade; Food, Agricultural and Pharmaceutical Grade; Optical Grade, USP and EP/BP (European Pharmacopoeia/British Pharmacopoeia) and follows applicable ASTM testing standards. Typical and custom packaging is available, as is additional technical and safety (MSDS) data. Please contact us for information on lead time and pricing above.
Aluminium Metal Foam Related Information
Storage Conditions:
Airtight sealed, avoid light and keep dry at room temperature.
Please contact us for customization and price inquiry
Email: contact@nanochemazone.com
Note: We supply different size ranges of Nano and micron as per the client’s requirements and also accept customization in various parameters.
Description
Description
Note: For pricing & ordering information, please contact us at sales@nanochemazone.com
Please contact us for quotes on Larger Quantities and customization. E-mail: contact@nanochemazone.com
Customization:
If you are planning to order large quantities for your industrial and academic needs, please note that customization of parameters (such as size, length, purity, functionalities, etc.) is available upon request.
NOTE:
Images, pictures, colors, particle sizes, purity, packing, descriptions, and specifications for the real and actual goods may differ. These are only used on the website for the purposes of reference, advertising, and portrayal. Please contact us via email at sales@nanochemazone.com or by phone at (365) 888-7013 if you have any questions.
