| Product Name |
AlSi10Mg Powder
|
| CAS No. |
7429-90-5 |
| Appearance |
Powder |
| Purity |
≥99.9% |
| APS |
1-5 µM, 10-53 µM (Can be customized),
Ask for other available size range. |
| Ingredient |
AlSi10 Mg |
| Product Code |
NCZ-24AV-151 |
Our company’s gas atomized AlSi10Mg powder, good sphericity, low oxygen content, good fluidity.at present, aluminum alloys used in metal 3D printing mainly include AlSi12 and AlSi10Mg, they are lightweight additive metal powders with good thermal properties, It can be applied to thin-wall parts such as heat exchangers and other automotive parts, and also can be applied to aerospace and aerospace industrial grade prototype and production parts; The silicon/magnesium combination gives aluminum alloy strength and hardness, making it suitable for thin-walled and complex geometries, especially in applications with good thermal properties and low weight.
Due to its superior performance of light weight and high strength, magnesium aluminum alloy has been widely used in the lightweight demand of manufacturing industry. In 3D printing technology, it has also become the preferred candidate material of various manufacturers without exception.
Product Specification
| Component |
Al |
Si |
Mg |
Fe |
Pb |
Ni |
| Standard % |
Bal. |
9.0-12.0 |
0.25-0.45 |
≤0.55 |
≤0.05 |
≤0.05 |
| Test% |
Bal. |
10.26 |
0.37 |
0.13 |
0.02 |
0.01 |
| Component |
Ti |
Mn |
Cu |
Zn |
O |
|
| Standard % |
≤0.01 |
＜0.01 |
− |
− |
− |
|
| Test% |
0.005 |
0.005 |
0.01 |
0.01 |
0.059 |
|
Product Specification
PSD
|
|
| Size
(µM) |
Flowability
(s/50g) |
PSD (µM) |
|
|
| D10 |
D50 |
D90 |
|
|
| 15-45 µM |
＜90 |
15-25 |
30-35 |
40-50 |
| 15-53 µM |
＜90 |
15-21 |
25-30 |
45-55 |
| 45-120 µM |
＜50 |
53-57 |
89-93 |
144-152 |
|
|
|
|
|
|
Product Features
Good thermal conductivity and wear resistance.
Low thermal expansion coefficient.
Light weight.
High strength.
Applications
Gas atomized spherical powder can be used for 3D Printing, Spraying, Brazing, Electronic, Powder metallurgy industry, Solar industry, The lithium battery and other processing technology.
AlSi10Mg Powder Properties /Description
AlSi10Mg Powder is generally immediately available in most volumes. Nanochemazone produces many standard grades when applicable, including Mil Spec (military grade); ACS, Reagent and Technical Grade; Food, Agricultural, and Pharmaceutical Grade; Optical Grade, USP and EP/BP (European Pharmacopoeia/British Pharmacopoeia) and follows applicable ASTM testing standards. Typical and custom packaging is available. Additional technical, research, and safety (MSDS) information are available, as is a Reference Calculator for converting relevant units of measurement.
Related Information:
Storage Conditions:
Airtight sealed, avoid light, and keep dry at room temperature.
Please get in touch with us for customization and price inquiry
Email: contact@nanochemazone.com
Note: We supply different size ranges of Nano and micron as per the client’s requirements and accept customization in various parameters.
