TA15 Titanium Alloy Powder
| Product Name |
TA15 Titanium Alloy Powder
|
| CAS No. |
7440-65-5 |
| Appearance |
Dark Brown Powder |
| Purity |
≥99.9% |
| APS |
1-5 µM, 10-53 µM (Can be customized),
Ask for other available size range. |
| Ingredient |
Ti-6.5Al-2Zr-1Mo-1V |
| Melting point |
1522°C |
| Boiling point |
3338°C |
| Product Code |
NCZ-24AV-115 |
TA15 (Ti-6.5Al-2Zr-1Mo-1V) alloy is a common near-alpha titanium alloy, which has excellent mechanical properties such as high specific strength, good thermal stability, creep resistance, weldability and processing plasticity. Widely used in the manufacture of aircraft parts, engine parts and welded load-bearing parts that work for a long time below 500 °C. Mana adopts the EIGA type electrode induction gas atomization powder making technology. The research and development team has improved the powder making equipment and optimized the process. The spherical titanium powder prepared has low oxygen and low nitrogen, high fine powder yield, uniform particle size distribution, and spherical titanium powder. It has the characteristics of high conversion rate, good sphericity, high surface finish, good fluidity, and high bulk density, which fully meets the performance requirements of 3D printing, hot isostatic pressing, injection molding, and laser cladding.
Product Specification
| Chemical Composition of Titanium Alloy Powders |
|
|
| |
|
| Brand |
Ti |
Al |
Mo |
V |
Zr |
Si |
Fe |
C |
N |
H |
O |
|
| TC4 ELI(Ti-6Al-4V ELI, GR23, Ti64ELI) |
Bal. |
5.5-6.5 |
－ |
3.5-4.5 |
－ |
－ |
≤0.30 |
≤0.08 |
≤0.05 |
≤0.015 |
≤0.13 |
|
| TC4 ELI(Ti-6Al-4V, GR5, Ti64) |
Bal. |
5.5-6.75 |
－ |
3.5-4.5 |
－ |
－ |
≤0.30 |
≤0.08 |
≤0.05 |
≤0.015 |
≤0.15 |
|
| TA1(GR1, Ti1) |
Bal. |
－ |
－ |
－ |
－ |
－ |
≤0.25 |
≤0.10 |
≤0.03 |
≤0.015 |
≤0.15 |
|
| TA15(Ti-6.5Al-1Mo-1V-2Zr) |
Bal. |
5.5-7.1 |
0.5-2.0 |
0.8-2.5 |
1.5-2.5 |
≤0.15 |
≤0.25 |
≤0.08 |
≤0.05 |
≤0.015 |
≤0.15 |
|
| TA11(Ti-6.5Al-3.5Mo-1.5Zr-0.3Si) |
Bal. |
5.8-7.0 |
2.8-3.8 |
－ |
0.8-2.0 |
0.2-0.35 |
≤0.25 |
≤0.08 |
≤0.05 |
≤0.012 |
≤0.15 |
|
Particle size:0-25μm, 14-45μm, 15-53μm, 53-105μm, 105-150μm
Customized according to customer requirements
Product Features
- The powder has High purity low oxygen. Low nitrogen.
- High yield of fine powder, Good spherical.
- Uniform particle size distribution, High surface finish
- Excellent Flowability, High Apparent density
- Competitive cost
Application
The high-quality gas-atomized spherical titanium alloy powder produced by Mana can be widely used in military and civilian fields such as aviation, aerospace, weapons, machinery, etc..
Applicable manufacturing processes mainly include:
Additive manufacturing (AM)
Selected Laser Melting (SLM)
Electron Beam Melting (EBM)
Laser Engineered Net Shape (LENS)
Powder Metallurgy (PM)
Metal powder Injection Molding (MIM)
Hot Isostatic Pressing (HIP)
Laser Cladding (Repair)
TA15 Titanium Alloy Powder Properties /Description
TA15 Titanium Alloy Powder is generally immediately available in most volumes. Nanochemazone produces many standard grades when applicable, including Mil Spec (military grade); ACS, Reagent and Technical Grade; Food, Agricultural, and Pharmaceutical Grade; Optical Grade, USP and EP/BP (European Pharmacopoeia/British Pharmacopoeia) and follows applicable ASTM testing standards. Typical and custom packaging is available. Additional technical, research, and safety (MSDS) information are available, as is a Reference Calculator for converting relevant units of measurement.
Related Information:
Storage Conditions:
Airtight sealed, avoid light, and keep dry at room temperature.
Please get in touch with us for customization and price inquiry
Email: contact@nanochemazone.com
Note: We supply different size ranges of Nano and micron as per the client’s requirements and accept customization in various parameters.
