Ruthenium Paste for Thick Film Circuits

Product Name	Ruthenium Paste for Thick Film Circuits
CAS No.	14898-67-0
Appearance	Powder/Paste
Purity	≥99.9%
APS	1-15µM (Can be customized)
Ingredient	Ru
Product Code	NCZ-24AV126

Ruthenium Paste for Thick Film Circuits is mainly used in the production and preparation of thick film circuits and related separated components. Product Properties: 1. Physical Properties Recommended Using Process: 1. Stirring: Gently stir well before use. 2. Recommended…

Ruthenium Paste for Thick Film Circuits

PR-Ru-4500 Series is mainly used in the production and preparation of thick film circuits and related separated components.

Product Properties:

Physical Properties

Grade	NCZ-PR-Ru-4500 Series
Solid Content	70-80%
Particle Size (µm)	≤10
Viscosity (Pa.S)	500±100
Benchmarking:
Performance	4511	4521	4531	4541	4551	4561	4571
Electrical Resistivity (Ω/□）±15%	10	100	1K	10K	100K	1M	10M
Temperature Coefficient of Resistance（PPM/℃）	±100	±100	±100	±100	±100	±100	±100
Temperature Coefficient of Resistance（V/mm）	2.8	8.84	28	88	280	400	400
Dipping Solder(△R%)	±0.5	±0.5	±0.5	±0.5	±0.5	±0.5	±0.5
Noise(dB)	<-25	-20	-10	-5	-5	0	0
Room Temperature Storage(25℃、1000h、△R%）	±0.5	±0.5	±0.5	±0.5	±0.5	±0.5	±0.5
Hot Flash test（△R%）40℃、94%RH 250h ）	±0.5	±0.5	±0.5	±0.5	±0.5	±0.5	±0.5
Thermal Stability （△R%）150℃、250h）	±0.5	±0.5	±0.5	±0.5	±0.5	±0.5	±0.5
Temperature Cycle（△R%）-55℃-125℃、5times）	±0.2	±0.2	±0.2	±0.2	±0.2	±0.2	±0.2

Recommended Using Process:

Stirring: Gently stir well before use.
Recommended Printing Thickness: 20±2µm
Mesh Material And Mesh: nylon mesh inch 250-300 mesh

Stainless Steel Wire Mesh: Inch 260-325 Mesh

Drying: After printing, place it in a 150℃ oven or under an infrared light for 15 minutes.
Sintering Process (Recommended): Sintering in tunnel furnace, sintering peak temperature 850℃, peak

Value holding time 10 minutes, sintering cycle 45-60 minutes.

Attention:

Safe use: The paste is harmful if swallowed, inhaled or in contact with the skin, so use wash thoroughly immediately after, avoid contact with eyes, skin or clothing, keep away tinder or burning material. Because it is flammable, cover it tightly when not in use to avoid inhalation of volatilization gas, keep air circulation when using.
This paste is a ready-to-use product and does not need to be diluted. If it needs to be diluted, the amount added should not exceed

3% (weight ratio), too much diluent will directly affect the performance of the slurry.

The thickness of the printed circuit itself should not be less than 4μm, otherwise the electrical conductivity will be unstable.
This slurry should be stored in a cool and dry place between 4~25℃.
Storage period: The original package is sealed for six months.

Ruthenium Paste for Thick Film Circuits Properties /Description

Ruthenium Paste for Thick Film Circuits is generally immediately available in most volumes. Nanochemazone produces many standard grades when applicable, including Mil Spec (military grade); ACS, Reagent and Technical Grade; Food, Agricultural, and Pharmaceutical Grade; Optical Grade, USP and EP/BP (European Pharmacopoeia/British Pharmacopoeia) and follows applicable ASTM testing standards. Typical and custom packaging is available. Additional technical, research, and safety (MSDS) information are available, as is a Reference Calculator for converting relevant units of measurement.

Related Information:

Storage Conditions:

Airtight sealed, avoid light, and keep dry at room temperature.
